SEM9000 Micro automatic meteorological urban ambient air station

SEM9000 micro automatic meteorological station is a civil integrated meteorological station independently developed by our company, which can measure multiple meteorological parameters. It can simultaneously measure atmospheric temperature, atmospheric humidity, wind speed, wind direction, air pressure, rainfall, radiation, illuminance, UV radiation, PM2.5 and PM10 and other meteorological elements.

SEM9000 micro automatic meteorological station is a civil integrated meteorological station independently developed by our company, which can measure multiple meteorological parameters. It can simultaneously measure atmospheric temperature, atmospheric humidity, wind speed, wind direction, air pressure, rainfall, radiation, illuminance, UV radiation, PM2.5 and PM10 and other meteorological elements.

SEM9000 uses low-power chip, and the power consumption is only 1.7w. Due to the adoption of new technology and new process, the structure is more compact and compact. Mini visibility detection module can also be selected, which is very suitable for smart city control system. The shell is ABS engineering plastic, and according to the user’s requirements, all the test parameters can be selected and combined at will, completely customized.

Parameters

ITEMS

Range

Accuracy

Stability

Response time

Wind speed

0~40m/s (0.5m/s start)

±0.5+2%FS

1S

Wind direction

0-359 °

±3 °

1S

Temperature

– 40 ℃ – + 80 ℃

±0.5℃(25℃)

≤0.1℃/y

≤1s

Humidity

0%RH~99%RH

±3%RH(60%RH,25℃)

≤1%/y

≤1s

Atmospheric pressure

0-120Kpa

±0.15Kpa@25℃ 75Kpa

-0.1Kpa/y

≤1s

Noise

30dB~120dB

±3db

≤3db/y

≤1s

PM10 PM2.5

0-1000ug/m3

±10%(25℃)

≤1%/y

≤90S

Illuminance

0-200000lux

±7%(25℃)

≤5%/y

≤0.1s

Rainfall*

24mm/min (Max. instantaneous rainfall)

±5% (Accuracy)

6cm (Sense of rain diameter)

0.1mm (Resolution )

Digital output

RS485(Modbus)

Power supply

10V-30V DC

IP protection

IP65

Operating environment

-40℃ – 70 ℃, 0-100%RH

Power consumption

0.7W

Material

White/ABS+Aluminum alloy
