Water flow meter is essential devices used to measure the flow rate of water in various applications. They provide accurate data that helps in monitoring and managing water consumption. Whether in a residential, commercial, or industrial setting, understanding the different types of water flow meters is crucial for choosing the right one for your specific needs.
How Does a Water Flow Meter Work?
Before delving into the various types of water flow meters, it is essential to understand how they work. Most water flow meters operate on the principle of either volumetric or velocity measurements.
Volumetric water flow meters measure the volume of water passing through the meter. These meters typically consist of a chamber or a rotating rotor that fills up with water as it flows through the device. The rotation of the rotor is then measured, providing an accurate measurement of the water volume.
Velocity-based water flow meters, on the other hand, measure the speed of the water flow. These meters employ different techniques such as ultrasound, electromagnetic, or turbine-based measurements to determine the flow rate.
Digital Water Flow Meter
Digital water flow meters have gained popularity in recent years due to their accuracy and ease of use. These meters utilize digital technology to provide precise measurements of water flow rates.
One of the significant advantages of digital water flow meters is their ability to display real-time data. The digital display allows users to monitor the flow rate instantly, enabling them to make informed decisions regarding water consumption.
Digital water flow meters also offer features like data logging, which allows for the recording of flow rates over a specific period. This data can be analyzed to identify trends and patterns, aiding in efficient water management.
The Different Types of Water Flow Meters
Most popular digital water flow meters include rotameter flowmeters, turbine water flowmeters, electromagnetic water flowmeters, and vortex flowmeters for water volume measurement, positive displacement flowmeters, differential pressure flowmeters, Coriolis water mass flowmeter and ultrasonic water flowmeter, the following is a description of the principle, features, application overview for different digital water flow meter types.
Turbine digital water flow meter
Turbine flowmeter for water measurement
Turbine flowmeter is a kind of velocity flowmeter. Turbine flow transmitter uses a multi-blade rotor (turbine) to sense the average water flow rate, then deriving the water flow rate or water total. Generally, it consists of a flow sensor and an integral display instrument to show water detecting information and turbine water meter parameter setting.
Turbine flowmeters, positive displacement flowmeters, and Coriolis mass flowmeters are known as the best repeatability and accuracy comparing with other types flow meters. SenTec can offer turbine meter as cheap inline water flow meter.
Advantages to use turbine flow meter for water metering:
(1) High precision can reach accuracy 0.5% to 0.25%:
(2) Good repeatability:
(3) Inline digital water flow meter has no zero drift, good anti-interference ability;
(4) Digital turbine flow transmitters to have LCD display to read water flow rate and cumulative water total flow;
(5) 4-20mA and pulse output, RS485 communications possibility;
(6) Battery operated water flow meter or 24V DC power supply
(7) Wide range for water measurement
(8) Compact structure and light weight for easy transportation
(9) Inline water flow meter with various size, from low flow rate water flow meter with only 1/8 inch dial size to 10”, DN250 water flow meter, normal buy water flow meter sizes are :1/2” water flow meter, 1 inch water flow meter, 2 inch digital water flow meter GPM, 3”, 4 inch and DN150 water turbine flow meters;
Application for turbine water flow meter:
Turbine flowmeters are widely used in the following measurement objects: petroleum, organic liquids, inorganic liquids, liquefied gas, natural gas and cryogenic fluid systems. Only clean water can be measured by inline digital water flow meter turbine type, such as tap water, drinking water, RO Reverse Osmosis water, clean water, soft water, pure water, mineral water, distilled water, bottle water, dirty or slurry water should go for magnetic water flow meter.
Vortex Digital Water Flow Meter
Vortex flowmeter for water measurement
Vortex flowmeter is an instrument that places a bluff vortex generator in the water, and the fluid is alternately separated on both sides of the generator to release two series of regularly staggered vortices.
Vortex flowmeter can be divided into: stress type, strain type, capacitive type, thermal type, vibrating body type, photoelectric type and ultrasonic type according to the frequency detection method. Vortex flowmeter is the youngest type of flowmeter. However, it has developed rapidly and has now become a common type of flowmeter.
Advantages for water measurement by Vortex flow meter
(1) Simple and firm structure, without moving parts inside flow sensor
(2) Suitable for many types of fluids, such as normal clean water, high temperature water flow measurement, condensed water flow meter, fully demineralized water, boiler feedwater, digital hot water flow meters; the max water temperature by vortex flow meter is 300 °C.
(3) Accuracy: 1.0% for water flow measurement
(4) Wide range, turn down ratio for water is around 1:10;
(5) Inline digital water flow meter small pressure loss in the closed water pipeline;
(6) Industrial digital water flow meter with electronic indicator, current output and 4-20Ma, pulse output or HART protocol;
Electromagnetic Digital Water Flow Meter
Electromagnetic flowmeter for water flow measurement
Electromagnetic flowmeter is a kind of instrument for measuring conductive water made according to Faraday’s law of electromagnetic induction. Electromagnetic flowmeter has a series of excellent features, which can solve the problems that other flowmeters are not easy to apply, such as the measurement of dirty water flow and corrosive water flow;
Advantages of magnetic water flow meter
(1) The measurement tube of magnetic water flow sensor is a smooth straight pipe, which will not be blocked by passing water, and is suitable for dirty water measurement, such as sewage, waste water, pulp water, mud water, industrial wastewater, raw water, ground water geothermal water at 120°C,effluent water, fire fighting water, ;
(2) No pressure loss caused by water flow detection , the energy saving effect is good;
(3) the measured volume flow is actually not significantly affected by changes in water density, viscosity, temperature, pressure and conductivity:
(4) The flow range is large and can be made into large size water flow meter, such as 8inch water flow meter, 10” water meter, 12inch, DN500,DN600,DN900, 1000mm dial size water flow meters;
(5) Mag water flow meter not only measure dirty water flow, but also can be made into acid water flow meter or NaOH water flow meter, such as water solution with HCL, Nitric Acid, sulfuric acid.,etc
(9) Digital magnetic water flow meter can be with integral or remote display, option with MOBUS ,HART and profibus-DP water flow meters;
(10) Magnetic water flow meter has may flow units for water measurement, such as m3/h, GPM, gph, kg/h, TPH.,etc
Electromagnetic flowmeter Application overview:
Electromagnetic flowmeters are widely used, and large-diameter size magnetic water meters are mostly used in water supply and drainage projects: medium and small size mag meters are often used in high-demand or difficult-to-measure occasions, such as the control of cooling water in blast furnace tuyere in the iron and steel industry, and the measurement of pulp and black liquor in the paper industry. Strong corrosive liquid in chemical industry, ore pulp in non-ferrous metallurgical industry; small-diameter and micro-diameter are often used in places with hygiene requirements such as pharmaceutical industry, food industry, and biochemistry.
It is a kind of induction meter measuring the volume flow of conductive media. In addition to measuring the volume flow of normal conductive liquid, it can be used to measure the volume flow of strong corrosive liquid, such as strong acid and alkali, as well as mud, pulp, etc. It is widely used in oil, chemical, metallurgy, light spinning, paper making, environmental protection, food and other industries and municipal management, water conservancy construction, river dredging and other areas of flow measurement.
Variable Digital Water Flow Meter
Variable area flow meter for water flow measurement
Variable area flow meter, also known as Float flowmeter, rotameter, it is a widely used cheap water flow meter. In a vertical conical tube that expands from bottom to top, the gravity of the float with a circular cross section is borne by the hydrodynamic force, so the float can rise and fall freely in the cone tube with water flow range change.
Float flowmeter is the most widely used classic DP flowmeter, it is especially perfect for small and micro flow water flow measurement.Float flow meters can be glass tube , plastic tube or metal tube variable area flow meter.
The glassl tube rotameter has a simple structure and is easy to use,it is a kind of very cheap rotameter to show water flow rate, cheap inline water flow meter.
The disadvantage of rotameter is that the pressure resistance is low, and there is a greater risk of the glass tube being fragile; VA flow meter for pipeline with small and low water flow measurement, the pressure loss is also very small.
SenTec sell metal tube rotameter, it can be mechanical rotameter without any power supply or metal tube rotameters with transmitters to have 4-20mA output,digital rotameter also has the possibility with HART or MODBUS for different process control or remote monitoring.
Differential pressure Digital Water Flow Meter
Differential pressure flowmeter for water measurement
Differential pressure flowmeter is an instrument that calculates the flow rate according to the differential pressure generated by the flow detection element installed in the pipeline, the known fluid conditions and the geometric dimensions of the detection element and the pipeline.
Differential pressure flowmeter consists of a primary device (detection piece) and a secondary device (differential pressure transmitter and flow computer). Differential pressure flowmeters are usually classified in the form of detection pieces, such as orifice flowmeters, Venturi flowmeters , V-cone flow meters.,etc
DP flow meters for water measurement has long history, it has stable performance and reliable measurement result.
It can be used for high pressure water flow measurement or high temperature water flow measurement , inline digital water flow meter.
Differential pressure flowmeter Advantages:
(1) The most widely used DP flow meter is orifice plate flowmeter , the DP flow sensor has a firm structure, stable and reliable performance, and long service life;
(2) DP flow meter has a wide range of applications, and so far there is no other type of flowmeter that can be compared with it; Transmitters and display instruments are produced by different manufacturers, which is convenient for easy replacement;
Differential pressure flowmeter Disadvantages:
(1) The measurement accuracy is generally low
(2) The rangibility is narrowing, generally only 3:1-4:1:
(3) Orifice plate need long straight pipeline when mounting the primary elements;
(4) Relative large pressure loss
Differential pressure flowmeter Application overview:
Differential pressure flowmeter has a wide range of applications. It is used in various fluids in the flow measurement of closed pipelines, such as clean water, high temperature water, industrial high pressure water.,etc
Ultrasonic Digital Water Flow Meter
Ultrasonic flowmeter for water measurement
Ultrasonic flow meters are instruments that measure flow by detecting the action of water flow on ultrasonic beams (or ultrasonic pulses).
According to the principle of signal detection, ultrasonic flowmeter can be divided into Transit time flow meter and Doppler flow meter.
Like electromagnetic flowmeters, ultrasonic flowmeters are unobstructed flowmeters because there is no obstruction in the water flow pipeline. They are a type of flowmeter suitable for solving difficult problems in flow measurement, especially in large water flow meters used in large-diameter pipeline.
Ultrasonic flowmeter Advantages:
(1) Non-contact water measurement, non-contact flow meter by just applying clamp on transducers on the pipe wall;
(2) No flow obstruction one the pipe, so no pressure loss;
(3) Low cost digital water flow meter for large water pipelines
Ultrasonic flowmeter Disadvantages:
The transit time ultrasonic water flow meter only apply for clean water measurement , cannot be used for waste water or water with suspended particles and air bubbles; Doppler water flow meter for waste water but with low measurement accuracy;
Coriolis Digital Water Flow Meter
Coriolis Mass water Flow Meter
Coriolis mass flowmeter (CMF) is a direct water mass flow meter made by using the principle of Coriolis force proportional to the mass flow when the fluid flows in the vibrating tube.
Coriolis water flow meter price is not cheap and normally not very economical solution for water measurement; it is very high accuracy water mass flow meter, the accuracy can be 0.1%.
Coriolis flow meter is stainless steel water flow meter, we have 6mm, DN10, 1/2 inch, 1 inch , 2inch Coriolis water flow meters;
Digital water mass flow meter can also show water density on the flow meter electronic display;
Can measure different kinds of water, drilling mud, slurry pulp, sludge.,etc., inline digital water mass flow meter.
Positive displacement Digital Water Flow Meter
Positive Displacement water Flowmeter
Positive displacement flowmeter, referred to as PD flowmeter, is the most accurate type of flowmeter. It uses mechanical measuring elements to continuously divide the fluid into a single known volume part. According to the measurement the total fluids volume is measured by the number of times the chamber repeatedly fills and discharges a portion of that volume of fluid. Household water meters are PD flow meters, but in industry water flow measurement, SenTec developed a kind of micro PD flow meter for low flow water measurement. The water low flow can detect as low as 1 cc/min flow still with 0.5% high accuracy.
This kind of low flow PD flow meter can be used in Deep Water Sampling, chip cutting, water treatment system, odorizing system, coolant ,ammonia water,perfume measurement.,etc;
Low water flow range can be detected by PD flow meter:
0.5-150 ml/min,1-400 cc/min,1-800 ml/min,0.5-100LPH,0.2-21 CFM, 0.3-30 LPM, 0.1-26 GPM water flow;
Digital water flow meter with pulse NPN or PNP mode;
No straight pipeline need in the upstream and downstream of PD water
Choosing the Right Water Flow Meter for Your Application
Selecting the appropriate water flow meter for your specific application requires careful consideration of several factors. These factors include the flow rate range, pressure and temperature conditions, the type of liquid being measured, and the required accuracy.
For instance, if you need to measure water flow in a residential setting, a digital water flow meter with a wide flow rate range and good temperature resistance would be suitable. On the other hand, in an industrial environment, where high flow rates and harsh conditions are common, an electromagnetic flow meter with excellent pressure and temperature capabilities would be more appropriate.
It is also important to consider the long-term maintenance requirements and the availability of spare parts for the chosen water flow meter. Additionally, consulting with experts or manufacturers can provide valuable insights into selecting the most suitable meter for your specific needs.
Installation and Maintenance of Water Flow Meters
Proper installation and regular maintenance are crucial for ensuring the accurate and reliable operation of water flow meters. When installing a water flow meter, it is important to follow the manufacturer’s guidelines and consider factors such as the pipe size, orientation, and straight pipe requirements.
Regular maintenance includes cleaning the meter, checking for any leaks or obstructions, and calibrating the meter if necessary. It is also advisable to monitor the performance of the flow meter regularly to identify any potential issues and address them promptly.
Conclusion
Understanding the different types of water flow meters is essential for effectively monitoring and managing water consumption. By choosing the right water flow meter for your specific application and maintaining it properly, you can ensure accurate measurements and efficient water management.
Whether it’s a turbine flow meter, an ultrasonic flow meter, or any other type, each water flow meter has its advantages and limitations. Consider the specific requirements of your application, consult with experts, and select the most suitable water flow meter to meet your needs.
Investing in a quality water flow meter is a wise decision that can lead to significant cost savings and environmental benefits. By accurately measuring water flow rates, you can identify inefficiencies, detect leaks, and implement effective water conservation measures.
Start monitoring your water consumption today with the right water flow meter and take a step towards efficient water management.
